ID # 41370554

2025 John Deere MT9 Minimum-Till Ripper

Call for Price
Overview
  • 9 standards
  • Two stabilizer wheels
  • Integral or drawn options
  • Extended wear standards deliver twice the life expectancy
Specifications
Model
Ripper
Category Name
Agriculture
Year
2025
Sale Type
New
Manufacturer
John Deere
features

2025 John Deere MT9 Minimum Till RipperManage compaction faster

MT Series Minimum Till Rippers are built to run at 4 – 7 miles per hour behind today’s high horsepower tractors.



Rip 25 more acres per day with the MT11 compared to the previous 9 standard model.  MT Series Rippers break-up deep compaction at depths up to 16 in. while minimizing topsoil disturbance.

2025 John Deere MT9 Minimum Till RipperExtended wear components lead to higher productivity

Extended wear standards deliver double the  life expectancy compared to previous 2100 ripper models. The MT series delivers a highly productive and easy to set minimal maintenance solution to breaking up soil compaction. Spend less time changing components and more time working your ground.

2025 John Deere MT9 Minimum Till RipperTruSet™ Active maintains depth in changing conditions

TruSet Active provides better documentation of agronomic data and the ability to run prescription files.  With TruSet Active, operators can adjust depth from inside the cab.  Single point (manual) depth control is also included as standard equipment on drawn machines.



TruSet Active maintains the desired depth of the MT Series (with Drawn hitches).  When field conditions are challenging, TruSet Active uses ultrasonic technology to keep the ripper at desired depth regardless of mud on the tires, or when tires sink into soft soils.



See TruSet for additional information: TruSet™ features, packages, and documentation



Customers of competitive tractors and older John Deere tractors will need a TruSet™ compatibility kit.  Please see Compatibility for additional details for specific tractor models.



key specs
Working width 6.8 m
22.5 ft
Transport width 4.8 m
15.5 ft
Operating depth Maximum
40.6 cm
16 in.
Miles per hour 6.4-11.2 km/h
4-7 mph
Horsepower per standard 29.8-44.7 kW
40-60 hp
Spacing between standards 76.2 cm
30 in.



tool configuration
Type In-line ripper



operation depth
Maximum 40.6 cm
16 in.
frame
Size 152x152x9.5 mm
6x6x0.35 in.
Maximum underframe clearance 89 cm
35 in.



operating speed
Miles per hour 6.4-11.2 km/h
4-7 mph
horsepower required
Horsepower per standard 29.8-44.7 kW
40-60 hp
depth control
Option 1 3-point hitch for integral
Option 2 TruSet™ Active (with drawn hitch)
hitch
Options Integral
Optional: Drawn
Three-point hitch requirements Category 4N (with Quik-Coupler)
Pull-type description Category 5 Hitch
standard options
Spacing between standards 76.2 cm
30 in.
Option 1 Trip force
Shear-bol: 3,265 kg
7,200 lb
Standard type
Straight with wear shin: 19 or 31.75 mm
0.75 or 1.25 in.
Shear-bolt
Option 2 Trip force
1,451.5 kg
3,200 lb
Trip height
30.5 cm
12 in.
Standard type
19 mm
0.75 in.
Cushion trip
ground-engaging components
Options Standard: 19 mm (0.75 in.)
min-till point: 178 mm (7 in.)
low-disturbance: 254 mm (10 in.)
ultra-low-disturbance: 63 mm (2.5 in.)
Standard: 31.75 mm (1.25 in.)
Regular: 57 mm (2.25 in.)
Capped: 57 mm (2.25 in.)
Double-capped: 57 mm (2.25 in.)
LaserRip points: 70 mm (2.75 in.), 127 mm (5 in.), and 178 mm (7 in.)



coulters
Type Spring cushion coulters
Pounds of force Normal working load: 272.2 kg
600 lb
Deflection of: 10.2 cm
4 in.
Maximum trip load: 362.9 kg
800 lb
Deflection of: 20.3 cm
8 in.
Blades Straight or rippled: 559x4.5 mm
22x0.1777 in.
closing wheel attachment
Down force 113.4 kg
250 lb
Size 10.2x40.6 cm
4x16 in.
Spacing 19.05 to 35.6 cm
7.5 to 14 in.
Angle adjustments 1 to 15 degree (angle)
stabilizer/gauge wheels
Type Two Stabilizer wheels
Wheels 52.1x20.3 cm
20.5x8 in.
Tires 10 PR



pull-type wheels
Description VF320/70R15 Radial tire (with drawn hitch)
literature
Name Link
View Product Brochure Download
